SJ-140160 double stage plastic recycling machine
SJ-140160 double stage plastic recycling machine
تحویل اکسپرس
سفارشات بالای 1 میلیون تومان، شامل حمل رایگان هستند.
پرداخت امن
می توانید پرداخت را انلاین یا در محل، هنگام تحویل انجام دهید.
ضمانت اصالت کالا
استاندارد کیفیت هر محصول را تضمین می کنیم.
7 روز گارانتی بازگشت وجه
در صورت مشکل، میتوانید تا 7 روز محصول را مرجوع کنید.
PRODUCT INFORMATION
| Model | SJ-140 | SJ-160 | ||
| Yield | 250-300kg/h | 300-350kg/h | ||
| Applicable voltage | 380V/50hz/3ph | |||
| Screw | First stage | Diameter:140mm, length:3000mm, material: 38CR with vent, exhaust screw | Diameter:160mm, length:3200mm, material: 38CR with vent, exhaust screw | |
| Second stage | Diameter:120mm, length:1200mm, material: 38CR with vent, exhaust screw | Diameter:140mm, length:1200mm, material: 38CR with vent, exhaust screw | ||
| Gear box | ZLYJ：First stage：250;；Second stage：173 | ZLYJ：First stage：280;；Second stage：180 | ||
| Motor | First stage：55KW;Second stage：15KW | First stage：75KW;Second stage：18.5KW | ||
| Inverter | First stage | Adopt international famous brand: HOLIP55kw | ||
| Second stage | Adopt international famous brand: HOLIP15kw | |||
| Screen changer | First stage | Hydraulic upper and lower plate size:220mm * 220mm; working pressure: ≤ 35MPa | Hydraulic upper and lower plate size:250mm * 250mm; working pressure: ≤ 35MPa | |
| Second stage | Hydraulic upper and lower plate size:220mm * 220mm; working pressure: ≤ 35MPa | Hydraulic upper and lower plate size:250mm * 250mm; working pressure: ≤ 35MPa | ||
| Control box | Temperature control display:12Zone; Schneider and China ZHENGTAI products are used for electrical appliances | Temperature control display:13Zone; Schneider and China ZHENGTAI products are used for electrical appliances | ||
| Heating | Material: Ceramic；Heating voltage: 220 V / 50 Hz；Heating power: 2kw-3kw | |||
| Hopper | Open parallel hopper | |||
| Cooling system | Size ：2500*400*350mm Material ：Stainless | |||
| Fan | 1.5KW medium voltage motor; stainless steel water plate | |||
| Cutter system | Using 14 alloy hobs; grain size: 3-4mm; motor: 2.2kW | |||
| Oil box | Motor: 1.5kw, solenoid valve starts;hydraulic oil: 46 or 68;Oil storage capacity: 40L | |||
| Random accessories | Tool box (button switch, heating rod, electric couple, scissors, shovel, pliers, etc. are randomly distributed) | |||
