PRODUCT INFORMATION
Description
| Model | SJ-180 | SJ-200 | ||
| Yield | 350-400kg/h | 400-500kg/h | ||
| Applicable voltage | 380V/50hz/3ph | |||
| Screw | First stage | Diameter:180mm, length:3600mm, material: 38CR with vent, exhaust screw | Diameter:200mm, length:3800mm, material: 38CR with vent, exhaust screw | |
| Second stage | Diameter:160mm, length:1200mm, material: 38CR with vent, exhaust screw | Diameter:180mm, length:1200mm, material: 38CR with vent, exhaust screw | ||
| Gear box | ZLYJ：First stage：315;；Second stage：200 | ZLYJ：First stage：330;；Second stage：200 | ||
| Motor | First stage：90KW;Second stage：22KW | First stage：110KW;；副机Second stage：22KW | ||
| Inverter | First stage | Adopt international famous brand: HOLIP90kw | Adopt international famous brand: HOLIP110kw | |
| Second stage | Adopt international famous brand: HOLIP22kw | Adopt international famous brand: HOLIP22kw | ||
| Screen changer | First stage | Hydraulic upper and lower plate size:300mm *300mm; working pressure: ≤ 35MPa | ||
| Second stage | Hydraulic upper and lower plate size:300mm *300mm; working pressure: ≤ 35MPa | |||
| Control box | Temperature control display:15Zone; Schneider and China ZHENGTAI products are used for electrical appliances | Temperature control display:16Zone; Schneider and China ZHENGTAI products are used for electrical appliances | ||
| Heating | Material: Ceramic；Heating voltage: 220 V / 50 Hz；Heating power: 2kw-3kw | |||
| Hopper | Open parallel hopper | |||
| Cooling system | Size ：2500*400*350mm Material ：Stainless | |||
| Fan | 1.5KW medium voltage motor; stainless steel water plate | |||
| Cutter system | Using 14 alloy hobs; grain size: 3-4mm; motor: 2.2kW | |||
| Oil box | Motor: 1.5kw, solenoid valve starts;hydraulic oil: 46 or 68;Oil storage capacity: 40L | |||
| Random accessories | Tool box (button switch, heating rod, electric couple, scissors, shovel, pliers, etc. are randomly distributed) | |||
