PRODUCT INFORMATION

Categories	Printing Machine
Brand	Zhuxin
Model	YT6600-61000
Function	Flexible Printing Machine
Printing Color	2,4,6 color
Auto Tension Control	Depend on customers’ request
EPC	Depend on customers’ request
Air Shaft	Depend on customers’ request
Inverter	Delta / Shanghai NS
Main Motor	Simens / China Brand
Electric	Schneider /CHINT
Color	Orange and white
Air Pneumatic	Included
FOB port	Ningbo Sea Port
Terms of Payment	L/C,Western Union,MoneyGram,T/T

Specification:
1.six color 800mm flexo printing machine
2.different colors depend on customers’requirements .

width	1200mm

Flexographic printing machine, also called aniline press which uses photosensitive resin plate as the printing plate of printing machine. It adopts environmental ink and has advantage of low edition-producing cost , this is an ideal machine for mass lots , large variety production manufacturer It is also suitable for printing HDPE, LDPE, paper, rolling paper etc.

Characteristics :
1. operation,flexible starting accurate color register.
2. meter counter can set printing quantity according to the requirement.Stop the machine automatically at the set quantity or when the material is cut off.
3. Lift and lower the printing plate cylinder manually,It will automatically stir the printing ink after lifting.
4. printing ink is spread by the knurled cylinder with even ink color.
5. drying system coordinated with high-speed rotation,it will automatically break circuit when the machine stops.
6. 360 continuous and adjustable longitudinal register device.
7. frequency control of motor speed adapts to different printing speeds.
8. are inching/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Technical data:

Model	YT-6600	YT-6800	YT-61000
Max.width of subtrate	600mm	800mm	1000mm
Max.printing width	560mm	760mm	960mm
Range of printing length	200-1100mm	200-1100mm	200-1100mm
Max.diameter of unwinding & rewinding	Φ450	Φ450	Φ450
Printing speed	5-50m/min	5-50m/min	5-50m/min
Heating power	12kw	18kw	24kw
Total power machine	17kw	23kw	29kw
Outline diameter	4200x1660x2950mm	4200x1860x2950mm	4200x2060x2950mm
Weight	3500kg	4200kg	4500kg
Plate thickness(both side adhesive tape included)	2.38mm	2.38mm	2.38mm
